Description
NXP UHF UCODE 8 Laundry Labels EPC 128 bits, TID 96 bits (Pack of 100 tags ) Lan3515
Size: 35.0mm x15.0mm x 0.85mm
Fabric UHF RFID Laundry Tags are RFID tags specifically designed to be attached to fabrics/textiles. The washable UHF RFID laundry tag effectively identifies, tracks, and manages linen and textile assets. Ideal for establishments that require a continuous supply of clean linens, uniforms, workwear, medical apparel, or cleaning supplies, enabling automated systems to track large quantities of individual items more quickly and accurately.
UHF RFID Laundry Tags use UHF technology (860-960 MHz) and comply with international standards, including EPC Class1 Gen2 and ISO 18000-63. These textile laundry tags are flexible and durable, capable of withstanding over 200 wash cycles and 60 bar pressure. They also support mass reading from a distance of several metres
RFID Protocol:UHF EPC Class1 Gen 2, ISO18000-63
860-960MHZ NXP Ucode 8
EPC 128 bits ,TID 96 bits
Mounting Methods: Sewing/ Hot pressing (210°C,0.6 to 0.8MPa for 20 seconds)
Specifications:
128-bit/96-bit (UCODE 8/UCODE 8m) of EPC memory
Supports pre-serialization for 96-bit EPC
96-bit Tag IDentifier (TID) factory locked
48-bit unique serial number factory-encoded into TID
0-bit/32-bit (UCODE 8/UCODE 8m) User Memory
32-bit kill password to permanently disable the tag
32-bit access password
Wide operating temperature range
Washing tolerances:
Washing method: Wash or dry clean
Washing pressure resistance： 60 bars
Chemical resistance： Regular detergents, softeners, bleach (oxygen/chlorine), alkalis, etc.
Washing temperature: 90°С/15 minutes
Drying temperature: 180°С/30 minutes
Ironing temperature: 185°С/10 seconds
Sterilization temperature: 135°С/20 minutes
Working temperature & humidity: -20°С~＋ 85°С/8~95%RH.
Warranty: 200 cycles or 3 years,whichever comes first
Sold in packs of 100 tags
