Element P880DS Dual 2D Omni-directional Area Imager Omni-directional USB barcode scanner Kit
- Versatile Dual Omni-directional Area Imager
- 2-in-1 scanning solution
-
Front facing CMOS image sensor & Top facing CMOS 2D scanner
- Capable of Scanning 1D and 2D barcodes
The ELEMENT SCANNER KIT P880DS DUAL-2D USB BLK is a versatile and efficient Barcode scanner for capturing data from 1D and 2D barcodes. It has Dual-2D scanning technology, which allows it to read both traditional linear barcodes as well as more complex 2D barcodes such as QR codes and Data Matrix codes. This Hybrid 2D scanner has a front facing scanner which can scan barcodes, QR codes AND also has a top scanner built in for loyalty cards. The Front scanner, facing staff, would be used for scanning products/items and the Top scanner facing the customer is ideal for scanning customer loyalty cards.
The P880DS offers fast and accurate barcode scanning and can quickly decipher barcodes, which results in enhanced productivity and minimises errors in data capture, resulting in improved efficiency in various applications. It includes advanced features like motion tolerance and omnidirectional scanning. These capabilities enable users to scan barcodes from various angles and orientations, eliminating the need for precise alignment between the scanner and the barcode.
Specifications:
- Dimension (mm): 83mm x 80mm x 147mm
- Weight: 301g
- Voltage: 3.3-5 VDC
- Working Current: 200mA
- Front Scanner:
- Image (Pixels): 1280 pixels (H) x 1080 pixels (V)
- Light Source: Illumination: 6500K LED
- Field of View: 55° (H) x 47° (V)
- Roll / Pitch / Yaw: 360°, ±65° , ±60°
- Print Contrast: 15% minimum reflective difference
- Top Scanner:
- Image (Pixels): 640 pixels (H) x 480 pixels (V)
- Light Source: Illumination: 5000K LED
- Field of View: 40.5° (H) x 31° (V)
- Roll / Pitch / Yaw: 360°, ±65° , ±60°
- Print Contrast: 20% minimum reflective difference
- Interfaces Supported: USB-HID, USB-COM, RS232
- Motion Tolerance: >2m/s
- Symbology Decode Capability:
- 1D UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Codabar, Interleaved 2 of 5, Mis Plessey, GSI DataBar, China Postal, Korean Postal
- 2D PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin
- Operating Temperature: -30°C to 70°C
- Storage Temperature: -40°C to 70°C
- Humidity: 0% to 95% relative humidity, non-condensing
- Drop Specifications: Designed to withstand 1.5m (5’) drops
- Ambient Light Immunity: 0-100,000 Lux.
- Decode Ranges
- 3 mil (Code 39)0mm-20mm70mm-240mm
- 5 mil (Code 39)0mm-70mm70mm-310mm
- 6 mil (PDF 417)0mm-120mm30mm-330mm
- 13 mil (UPCA)0mm-170mm30mm-370mm
- 20 mil (QR)0mm-210mm
